Dual I/O modules per enclosure
OTAON K10-400L
June 2026 • Version 02
Max drives per unit:
60
Device support:
Dual-port SAS for high availability or single-port SATA for low cost
Max capacity per unit:
Up to 1.92PB
60 x 32TB SMR, 3.5 SAS/SATA & 2.5 SAS SSD
Expansion:
Up to 4 units may be daisy-chained for a total raw capacity of 7.68PB
OTAON K10-200M Overview
Features
Up to 60 HDDs (SAS or SATA) with a combination 24 SSDs + 36 HDDs for customers who want massive, shared storage
Up to 1.92PB of raw storage in 4U, and up to 4 units may be daisy-chained for a total raw capacity of 7.68PB
Optimized design minimizes vibration, ensuring consistent performance under heavy workload
Enhanced cooling architecture improves airflow for reliable operation and thermal efficiency
Choose dual-port SAS for high availability or single-port SATA for low cost
Enterprise-grade redundant and hot-swappable drives, PSUs, IO Modules, HEMs, and fans
Rack-mounted top cover for quick and easy service
Designed for high density and flexibility
Designed for next-generation disaggregated and software-defined storage (SDS), the platform delivers high-density capacity in an efficient form factor. It provides an optimal balance of performance, capacity, reliability, and energy-efficient operation
Designed for enterprise and cloud
Designed for enterprises, storage OEMs, and cloud service providers, the Hybrid Storage Platform delivers high-density shared storage with the flexibility to optimize capacity, performance, and cost.
Our Approach to Collaboration with Your Team
Understand unique customer requirements
Commitment to creating trust and long-term partnerships
Ensuring end-to-end transparency, security and compliance at every step
Enabling direct access to Kerno’s team of founders
IT Hardware Manufactured in the UAE
First enterprise-grade IT hardware manufacturer in the UAE
Manufactruring servers & other microelectronics solutions for the UAE
Best-in-class time for delivery
Leveraging Kerno's resilient supply chain with traceable Tier-1 components
Customer support fully based in the UAE
Reducing response time
Local R&D and production engineering team
Delivering engineering excellence in the UAE for the UAE
Intellectual Property (IP) rights
Fully owned by Kerno
State-of-the-art SMT line and high-end optical inspection machinery
Producing high tech solutions locally at Kerno's own manufacturing plant in the UAE
We look forward to understanding your goals & requirements
Features
Specifications
Controller
Host interface
Up to 12 x 24Gb/s SAS-4 host connections
Management
SCSI Enclosure Services Redfish (out of band, via RJ45)
Maximum system configuration
Up to 4 units may be daisy-chained for a total raw capacity of 7.68PB
Device support
Dual-port 12Gb/s SAS HDDs/SSDs & 6Gb/s SATA HDDs/SSDs
Max drives per enclosure
60
Hot-swappable components
Drives
PSUs
IO modules
HEMs
Fans
Dimensions
Height: 174.5 mm / 6.87 in
Width: 447.0 mm / 17.60 in
Depth: 712.0 mm / 28.03 in
Depth with CMA: 858.8 mm / 33.81 in
Weight
Product without drives: 27.3kg / 60lbs
Product with 60 HDDs: 80.67kg / 177.85 lbs
Power requirements — AC Input:
Input power requirements
Titanium: Dual 100-240V AC
Max power output per PSU
1600W
Environmental/temperature ranges:
Altitude
Operating: -300m to 3048m / -984 ft to 10,000 ft
Temperature
Operating: 5°C to 35°C
Non-operating: -40 to 70°C
Humidity
Operating: 5 to 85% relative humidity
Sound power
Operating: <7.2Bels @ 23±2°C
Cooling
4 main enclosure fans front-to-rear system cooling with zero-loss backflow prevention 1 IO module fan Dual PSUs with built-in fans
We look forward to understanding your goals & requirements
Your Customer Support Options
| Cruise | Performance | Full Throttle | |
|---|---|---|---|
| Onsite support | |||
| 24 × 7 × 365 help desk support | |||
| Access to spare & replacement parts | |||
| Onsite part replacement response | Next business day 8 a.m. to 5 p.m. UAE time Monday to Friday | Response within 4 hours 24 x 7 onsite service for severity 1 incidents | |
| Hardware replacement support | Customer performs replacement | Kerno’s engineer replaces hardware onsite | Kerno’s engineer replaces hardware onsite |
| Secure site coverage (keep failed HDDs/SSDs) | Optional | Optional | Optional |
| Advanced hardware troubleshooting | Remote guidance only | ||
| RMA (Return Merchandize Authorization) management | Customer packs and returns shipment using Kerno’s prepaid label | Service provider handles logistics and return processing | Service provider handles logistics and return processing |
| Return shipping prepaid by Kerno | |||
| Support hours | 24 × 7 help desk; replacement performed by customer | 8 a.m. to 5 p.m. UAE time Monday to Friday | 24 × 7 × 365 onsite support |
| Target response time | Best-effort remote assistance | Next business day | 4 hours (critical incidents) |
